Fast answer: Mount a horse feed tub where the horse can eat comfortably, the stall structure can support the hardware, feed stays away from water and bedding contamination, and staff can inspect and clean the feeder easily. The correct height and location depend on the horse and stall—not a single universal measurement.
The safest placement starts with the individual horse
Watch the horse eat before finalizing the installation. A miniature horse, pony, average saddle horse, and draft horse should not be expected to use the same wall height. The horse should be able to approach, lower its head comfortably, and eat without stretching upward or placing a leg near the basin.
If the horse paws, strikes, climbs, crowds doors, or has a history of catching equipment, work with the stall manufacturer or an experienced barn professional before mounting any fixed feeder.
Seven placement rules
- Use a structurally sound surface. Mounting hardware is only as dependable as the wall, panel, or framing holding it.
- Keep clear of doors and traffic. Avoid door swing paths, narrow entrances, blanket bars, cross-tie areas, and places where handlers or horses can be crowded against the feeder.
- Separate feed and water. Distance helps reduce feed dropped into water and splashed water turning dry feed into residue.
- Avoid heavy bedding zones. Do not place the tub where banked shavings, manure, or kicked bedding constantly collect.
- Leave cleaning access. Staff should be able to remove residue, inspect hardware, and rinse the basin without fighting the stall layout.
- Protect hardware clearances. Check both sides of the mounting surface for sharp ends, snag points, and interference with doors or neighboring stalls.
- Observe after installation. Watch several meals and adjust the setup if the horse eats awkwardly or creates a new safety concern.
Why the mounting system matters
The KD-121 Platinum 28-Quart Wall-Mount Feed Tub uses three U-bolts instead of asking one or two points to secure the entire tub. A reinforcing backer plate sits behind each U-bolt to help distribute mounting pressure through a broader area.
Install all supplied hardware as intended. Tighten evenly, but do not distort the tub by overtightening. Recheck the hardware after the horse has used the feeder and include it in routine stall inspections.
How high should a horse feed tub be?
Use horse-specific comfort and safety as the guide. The rim should not force the horse to reach upward, and the installation should not be so low that a hoof or leg can enter or become trapped. Stall design, feeder shape, bedding depth, horse size, and behavior all change the correct answer.
A practical installation process is:
- Stand the horse in the stall and observe its relaxed feeding posture.
- Hold or temporarily position the empty feeder against the intended wall.
- Check approach, head position, leg clearance, door clearance, and staff access.
- Mark all mounting points only after the location passes those checks.
- Follow the stall manufacturer’s instructions for drilling and hardware support.
Feed tub, corner feeder, or ground feeder?
- KD-121 Wall-Mount Tub: best all-around choice for a permanent open stall-feeding station.
- KD-136 Corner Feeder: useful when the stall corner provides the safest, cleanest installation.
- KD-168 Pan Feeder: portable floor-level option when permanent mounting is not appropriate.
- KD-173 Ground Feeder: broad-base choice for pens, paddocks, and animals that move lighter pans.
Reducing feed pushed over the rim
Placement cannot correct every messy eating habit. If a horse noses or sorts feed over the KD-121 rim, add the KD-122 Feed Saver Ring. It snaps onto the tub lip and fits over the U-bolts to help keep more feed inside.
Daily and monthly checks
Daily: remove old feed, check for contamination, and look for anything loose, sharp, cracked, or out of place.
Monthly—or more often in hard-use stalls: inspect U-bolts, backer plates, wall structure, tub lip, nearby hardware, and clearances. Tighten or repair equipment before it becomes a larger problem.
Common mistakes
- Using one “standard height” for every horse
- Mounting into a weak surface
- Placing feed directly beside water
- Installing in a door or handler traffic path
- Ignoring how the horse paws, noses, or crowds the feeder
- Leaving no room for cleaning and inspection
- Using only part of the supplied mounting system
Frequently asked questions
Should feed and water be separated?
Yes. Separation generally helps keep feed drier, water cleaner, and both routines easier to manage.
Can I mount a feed tub on any stall wall?
No. Confirm that the structure and hardware are appropriate for a loaded feeder and the forces a horse may place on it.
How often should mounted feed tubs be inspected?
Give the feeder a quick visual check during daily cleaning and perform a closer hardware and structure inspection regularly.
